Bidim® Green is a premium nonwoven geotextile made from Australian recycled polymers, designed to provide an effective and economical solution to a multitude of engineering applications.
Bidim® Green nonwoven geotextiles provide an effective, economical and sustainable solution to a range of engineering problems including weak soil, rutted and cracked roads and liquid and gas leaks from landfill sites. All Bidim® Green nonwoven geotextiles are manufactured in Australia to ISO 9001 standards and are supported by a rigorous MQA process as well as being designed to meet the requirements of Australian and New Zealand road authorities.
Bidim® Green nonwoven geotextiles provide excellent filtration and feature a strong three-dimensional structure with high elongation. Bidim® Green nonwoven geotextiles also have a high melting point and high UV resistance.
Geofabrics is a proud member of the Infrastructure Sustainability Council of Australia (ISCA). Bidim® Green is now available on ISupply.
Function
Drainage
Bidim®Green nonwoven geotextiles have a three-dimensional structure designed to improve drainage performance. Ideal for use in subsoil drainage systems, Bidim® Green will assist in the removal of water from road and railway works, sports fields and behind retaining walls.
Separation
Bidim® Green nonwoven geotextiles can be used in the construction of roads, railways and embankments where the ground is soft and unstable. Using a layer of geotextile to separate the soft ground from the fill material will reduce the amount of fill required, increase the life span of the road or rail structure and cut long-term maintenance costs.
Filtration
Bidim® Green nonwoven geotextiles are highly porous, allowing water to pass through while preventing soil migration. When used in revetment and subsoil drainage projects, Bidim® Green geotextiles are more cost-effective than natural filters.
Protection
Using heavyweight bidim® Green nonwoven geotextiles in landfills extends the life of the lining system by protecting it from punctures and excessive deformation. The geotextile acts as a cushioning and stress relieving layer, minimising the chances of leakage in the long term. Needle-free geotextiles are commonly specified in landfill and containment applications to prevent damage to the underlying liner.
Applications
Roads
Nearly every road built today uses a nonwoven geotextile such as Bidim® Green, to provide separation and filtration under the road formation. The ingress of water into road pavements poses the most significant damage potential to any road; therefore rapid removal of this water is of the utmost importance. Bidim® is the only bidimensional geotextile on the market today - meaning it has the same strength properties in both directions.
Standard road construction practice requires the inclusion of road edge drainage systems which incorporate geotextiles; in order to optimise the performance of these drains a geotextile with high flow rates is desirable. The three-dimensional structure of the nonwoven geotextile provides numerous flow paths, with the result that Bidim® Green geotextiles allow water to flow at rates which exceed most natural materials it is placed in contact with.
Rail Formation
Geotextiles are commonly used in the rail sector to separate the capping layer form the ballast layer, providing separation and filtration.
Embankments
The high-quality fill material can become contaminated when it is placed directly in contact with a soft or poor quality ground; the result being a loss of performance of the fill material. To limit the contamination and subsequent strength loss, geotextiles are used to separate the two distinct elements. Construction in this environment can place the geotextile separator under high stress with forces from rock placement and equipment loads needing to be transferred into the poor quality material. bidim Green geotextiles are ideal for this application as it combines high elongation with high strength to provide unsurpassed toughness and survivability characteristics.
Liner Protection
Heavy-duty geotextiles are used to prevent damage to impermeable liners designed to contain harmful liquors in landfill and mining applications; the design of the liner system needs to limit the chance of punctures during installation and reduce the risk of long term stress cracking of the geomembrane. Needle-free geotextiles are commonly specified in liner protection applications to help prevent damage to the liner.
Advantages
- Bidim® Green is made in Australia with Australian sourced recycled materials, reducing landfill waster.
- The incorporation of Bidim® Green geotextiles reduces the need for quarried fill materials and reduces construction times.
- Tightly rolled wide rolls can result in significant transportation cost savings.
- Local production of Bidim® Green allows full QA traceability of every roll, with many customers auditing our regional production facilities.
- Needle-free Bidim® Green geotextiles provide designers and installers in the waste and containment sectors with confidence that their liner will not be damaged.
- Geofabrics Research, Innovation and Development facility available for testing into the use of Bidim® Green as a cushion layer, yielding savings to contractors and asset owners.
- Local production of Bidim® Green allows for the production of project-specific grades or roll dimensions.
- Designed to meet the requirements of Australian road and rail authorities.
- Local stock holdings ensure we have the right product in the right place at the right time.
- Available on ISupply.
Installation
Bidim® Green geotextiles are supplied fully wrapped in rolls up to 6m in width to minimise wastage and laps. Bidim® Green is also available in a range of grades to meet the road, rail and waste authority specifications.
Installation can be assisted with the use of a Geofabrics supplied spreader bar.
